Vertical shaft mixers TMA


Horizontal double shaft mixers for productions from 1 to 3.5 m3 of compacted concrete. They can achieve a homogeneous mix with 90 second cycles (loading time not included)

The Alquezar TMA mixer admits aggregate of up to 80 mm, thanks to the design of the mixing arms, which can absorb impacts thanks to the damped anchorage by means of springs.

The mixer vat is entirely coated with non-wear sheet metal lining, whilst the mixing arms are made of cast iron.


Model TMA-2250/1500 TMA-3000/2000 TMA-4500/3000 TMA-5250/3500
Cycle capacity (m3) 1,5 2 2,5 3,5
Cycle time (s) *     90 90 90 90
Production (m3/h) 60 80 120 140
Engine power    55 75 110 135
Maximum aggregate size (mm) 80 80 80 80
Weight (kg) 4.800 6.800 10.800 11.100

*Excluding loading time
